Hope Car Beds

$1,500.00$1,600.00

-

The Hope Car Bed Standard is specially designed to allow small children with special health care needs who cannot use a traditional care seat lie prone while riding in an automobile.

  • Largest car bed available
  • Cummerband wrap provides comfort and optimal positioning
  • Maximum Weight: 35 lbs
  • Maximum Height: 29 inches (if legs are not permitted to bend)



  • Get Free Shipping on All Orders Over $30.
  • CARE CREDIT IS AVAILABLE for this product.
    Find out more at checkout.

Description

Hope Car Beds is designed for transportation of special needs children who cannot ride in a traditional car seat. The Hope Car Bed can accommodate an infant weighing from 4.5 lbs to 35 lbs and with height of up to 29″ long (if knees are bent). The Hope Car Bed is the best choice if the child will need to ride in the bed for a long time.

This bed offers five different methods of restraint and is intended for individual use, hospital loaner programs, or medical institutional use. The Hope Car Bed is also available in a version which accommodates children with hip casts more easily. The car bed can be installed in the rear seat on the right side, behind the passenger seat. This car bed is an ideal option for infants who need to travel on their stomach or side, cannot tolerate a semi-reclined position, or cannot use harness straps.

Product Benefits:

  • Provides slots for feeding medical tubes
  • Provides 5 different methods of restraint with 3 positions
  • Includes cummerbund, restraint bag, and three-point harness
  • Allows for transport of special needs children who cannot ride in a traditional car seat
  • Allows for transport of infants who need to travel on their stomach or side, cannot tolerate a semi-reclined position, or cannot use harness straps

Product Specifications / Dimensions

  • Minimum weight: 4.5 lbs
  • Maximum weight: 35 lbs
  • Maximum height: Up to 29″ (or taller if legs are permitted to bend

Additional Documentation on This Product

Product Information
Instructions for Use

More Information

The Hope Car Bed allows for five different methods of restraint: in the restraint bag with cummerbund or with the three-point harness and cummerbund, and in supine position, prone position, or on the right side. The recommended position for safety is supine. Prone or side positions should be used only when medically necessary.

The Hope Car Bed should only be installed in the rear passenger seat of the car with the child’s head facing the center of the vehicle. Two seat belts should be used to install the car bed. Whether you use the restraint bag or the three-point harness, the cummerbund should always be used. The harness and restraint bag are not meant for simultaneous use. A leveling wedge is available to keep the car bed level so the child is not lying tilted at an angle.

The Hope Car Bed can accommodate children up to 29″ without bending the knees, or slightly taller children with the knees bent.

Standard features of the Hope Car Bed include:

  • Neck pads
  • 3-point harness
  • Two locking clips
  • Medical tube guide
  • Small restraint bag
  • Two leveling/rebound straps
  • Small adjustable cummerbund
  • EPS foam sides and head protection/comfort cushion

Features of the restraint bag:

  • Available in two sizes – Small bag fits 4.5 lbs – 10 lbs, Large bag fits 10 lbs – 35 lbs
  • Available in standard or side-facing
  • A slot in the lower part of the bag for feeding gastro tubes through
  • Opening at the bottom for thermometer leads
  • Easy access to ventilation tubes
  • Features of the three-point harness:
  • Adjustable straps
  • A Velcro pad for feeding medical tubes through

Hope Car Bed Setup Instructions:To insert cummerbund with restraint bag:
1. Remove the 1.5″ foam side panel
2. Lay the cummerbund in the bed
3. Pushing the 3″ bottom cushion aside, insert the metal anchors into the side slots (there will be three slots on each side, use the middle slots)
4. Lay the restraint bag inside the cumberbund
5. Pushing the 3″ bottom cushion aside, insert the metal anchors into the side slots (there will be three slots on each side, use the outside slots)
6. Reinstall the 1.5″ foam side panel and reposition the 3″ bottom cushion
7. Insert the shoulder straps into the slots at the bottom of the 3″ cushion
8. Turn the bed over and connect the metal splitter plate to the straps
9. Pull the A-lock strap tight

To secure child in restraint bag with cummerbund:
1. Open restraint bag with dual zippers
2. Install the child and put their arms through the arm slots
3. Zip up the restraint bag
4. Close the cummerbund

To install harness with cummerbund:
1. Install the cummerbund
2. Lay the harness in the bed on top of the open cummerbund
3. Lift the flap at the bottom of the bed to insert the metal anchor into the slot
4. Insert the shoulder straps into the slots at the top
5. Turn the bed over and connect the metal splitter plate to the harness loops
6. Pull the a-lock strap tight

To secure child in harness:
1. Disconnect the harness buckle and chest clip
2. Lay the child in the bed on top of the cummerbund
3. Fasten the cummerbund around the child
4. Insert the latches into buckle to fasten the harness
5. Fasten the chest clip
6. The harness can be adjusted at the bottom
7. Pull the a-lock strap tight and cover it with the flap to keep it out of the way
8. Make sure the chest piece is level and the shoulder straps are tight

img-responsive

img-responsive

Additional information

Weight N/A
Dimensions N/A
Version

Hip Cast Version, Hope Car Bed Standard
